Supported Target Versions
CLI commands used in the application are
valid for all Eternus storage models.
Tested on an Eternus model with product code "ET203 BU"
with product name "Eternus DX200 S3"
which belongs to the "Eternus DX" product family.

Application Version and Upgrade Details

Application VersionBug fixes / Enhancements
1.0.6
  • Alter the monitoring values for eternus_drive_HealthPct metric, application will send 100% health if we get health % as sign
  • Alter the monitoring values for eternus_drive_enclosure_Status metric, if we get Drive Enclosure status as starts with Normal* is classed as Normal stateBug fixes - changed the few commands to get the response.
1.0.5Added support for NativeType Display order changes and resource grouping by type in UI.
1.0.4
  • Metric label support.
  • Missing component alert support.
Click here to view the earlier version updates
Application VersionBug fixes / Enhancements
1.0.3Full discovery Support.
1.0.2Bug fixes - changed the few commands to get the response.
1.0.1Activity logger related changes.
1.0.0Initial resource discovery and monitoring implementations.

Introduction

Eternus storage systems is a family of compatible all flash and hybrid storage systems. Eternus AF all flash arrays offer practically unlimited storage performance. Eternus DX hybrid storage systems are designed to store large amounts of unstructured data using cost efficient hard disk capacities while allowing fast access via SSDs. Eternus AF and Eternus DX offer an outstanding family of systems that allow the digital world to achieve the ideal balance between cost , capacity and speed.

Key Use cases

Discovery Use cases

The device discovery enables customers with an unified way of showing all of the elements making up a Eternus storage device along with the relationships.

Monitoring Use cases

The device monitoring helps to collect the metric values with respect to time and sends alerts to the intended customer team to act up immediately in case of any threshold breach or unexpected metric behavior observed based on configurations. In a way it helps the customer with smooth functioning of business with minimal or zero downtime in case of any infrastructure related issues occurring.

Prerequisites

  • OpsRamp Classic Gateway 14.0.0 and above.
  • OpsRamp NextGen Gateway 14.0.0 and above.
    Note: OpsRamp recommends using the latest Gateway version for full coverage of recent bug fixes, enhancements, etc.

Hierarchy of Eternus Storage

   Eternus Storage
        - Controller enclosure
        - Front-end enclosure
        - Drive enclosure
        - Disk drive
        - RAID Groups
        - Volume
        - Pool

Supported Metrics

Click here to view the supported metrics
Native TypeMetric NamesMetric Display NameUnitApplication VersionDescription
Eternus Storageeternus_storage_system_StatusEternus Storage System Status1.0.0Eternus Storage System Status. Possible Values are Normal:0,Empty:1,Pinned Data:2,Unused:3,Warning:4,Maintenance:5,Error:6,Loop Down:7,Not Ready:8,Subsystem Down:9,Change Assigned CM:10
eternus_storage_enclosure_StatusEternus Storage Enclosure Status1.0.0Eternus Storage System Enclosure Status.Possible Values are Normal:0,Other:1
eternus_storage_port_link_StatusEternus Storage Port Link Status1.0.0This metric represents Link status of SAS expander ports (the interfaces linking controllers and drive enclosures).Possible Values are Link Up:0,N/A:1,Link Down:2
Eternus Controller Enclosureeternus_controller_enclosure_StatusEternus Controller Enclosure Status1.0.0This metric displays the status of Eternus controller enclosure.Possible Values are Normal:0,Other:1.
eternus_controller_enclosure_intakeTemp_StatusEternus Controller Enclosure Intake Temperature Status1.0.0This metric displays CE intake temperature status.Possible Values are Normal:0,Other:1.
eternus_controller_enclosure_exhaustTemp_StatusEternus Controller Enclosure Exhaust Temperature Status1.0.0This metric displays CE exhaust temperature status.Possible Values are Normal:0,Other:1
eternus_controller_enclosure_CM_StatusEternus Controller Module Status1.0.0This metric displays the status of controller module of a controller enclosure.Possible values are Normal:0,Other:1.
eternus_controller_enclosure_PSU_StatusEternus Controller Enclosure PSU Status1.0.0This metric displays the status of power supply unit of a controller enclosure.Possible values are Normal:0,Other:1.
eternus_controller_enclosure_Disk_StatusEternus Controller Enclosure Disk Status1.0.0This metric displays the disk status of a controller enclosure.Possible Values are Available:0,Spare:1,Available(Predictive Failure):2,Present:3,Rebuild/Copyback:4,Broken:5,Not Available:6
eternus_controller_module_BusyRateEternus Controller Module Busy Rate%1.0.0This metric displays the controller modules busy rate in percentage
eternus_controller_module_CopyResidualQuantityEternus Controller Module Copy Residual QuantityMB1.0.0This metric displays the controller module copy residual quantity in MB
eternus_port_ReadIOEternus Port ReadIOIOPS1.0.0This metric displays the read IO of eternus host interface port(FC or iSCSI)
eternus_port_WriteIOEternus Port WriteIOIOPS1.0.0This metric displays the write IO of eternus host interface port(FC or iSCSI)
eternus_port_throughput_ReadEternus Port Throughput ReadMBps1.0.0This metric displays the read throughput of eternus host interface port(FC or iSCSI)
eternus_port_throughput_WriteEternus Port Throughput WriteMBps1.0.0This metric displays the write throughput of eternus host interface port(FC or iSCSI)
Eternus Frontend Enclosureeternus_frontend_enclosure_StatusEternus Frontend Enclosure Status1.0.0This metric displays the status of Frontend enclosure of eternus .Possible Values are Normal:0,Other:1.
eternus_frontend_enclosure_intakeTemp_StatusEternus Frontend Enclosure Intake Temperature1.0.0This metric displays the intake temperature status of frontend enclosure of eternus device.Possible values are Normal:0,Other:1.
eternus_frontend_enclosure_exhaustTemp_StatusEternus Frontend Enclosure Exhaust Temperature1.0.0This metric displays the exhaust temperature status of Frontend enclosure of eternus device.Possible values are Normal:0,Other:1
eternus_frontend_enclosure_FRT_StatusEternus Frontend Enclosure FRT Status1.0.0This metric displays the Front end Router status of Frontend enclosure of an eternus device.Possible values are Normal:0,Other:1.
eternus_frontend_enclosure_SVC_StatusEternus Frontend Enclosure SVC Status1.0.0This metric displays the service controller status of Frontend enclosure of an eternus device.Possible values are NOrmal:0,Other:1.
eternus_frontend_enclosure_FanUnit_StatusEternus Frontend Enclosure Fan Unit Status1.0.0This metric displays the FU status of Frontend enclosure of an eternus device.Possible values are Normal:0,Other:1.
eternus_frontend_enclosure_Operationpanel_StatusEternus Frontend Enclosure Operation Panel Status1.0.0This metric displays the operation panel status of Frontend enclosure of an eternus device.Possible values are Normal:0,Other:1.
eternus_frontend_enclosure_PSU_StatusEternus Frontend Enclosure PSU Status1.0.0This metric displays the power supply unit status of Frontend enclosure of an eternus device.Possible values are Normal:0,Other:1.
Eternus Drive Enclosureeternus_drive_enclosure_StatusEternus Drive Enclosure Status1.0.0This metric displays the status of drive enclosure of a eternus device.Possible values are Normal:0,Other:1.
eternus_drive_enclosure_intakeTemp_StatusEternus Drive Enclosure Intake Temperature1.0.0This metric displays the intake temperature status of DE of an eternus device.Possible Values are Normal:0,Other:1.
eternus_drive_enclosure_exhaustTemp_StatusEternus Drive Enclosure Exhaust Temperature1.0.0This metric displays the exhaust temperature status of a drive enclosure of eternus device.Possible values are Normal:0,Other:1.
eternus_drive_enclosure_IOM_StatusEternus Drive Enclosure IOM Status1.0.0This metric displays the status of I/O Module of a drive enclosure of eternus device.Possible values are Normal:0,Other:1
eternus_drive_enclosure_FEM_StatusEternus Drive Enclosure FEM Status1.0.0This metric displays the status of Fan expander module of a DE of eternus device.Possible values are Normal:0,Other:1.
eternus_drive_enclosure_PSU_StatusEternus Drive Enclosure PSU Status1.0.0This metric displays the PSU status of a drive enclosure of eternus device.Possible values are Normal:0,Other:1.
Eternus Disk Driveeternus_drive_StatusEternus Drive Status1.0.0This metric displays the status of disk drive of an eternus device.Possible Values are Available:0,Spare:1,Available(Predictive Failure):2,Present:3,Rebuild/Copyback:4,Broken:5,Not Available:6
eternus_drive_HealthPctEternus Drive Health Percentage%1.0.0This metric displays the health status of eternus disk drive in percentage
eternus_drive_BusyRateEternus Drive Busy Rate%1.0.0This metric displays the busy rate of eternus disk drive in percentage
eternus_drive_mediaerror_CountEternus Drive Media Error Countcount1.0.0This metric displays the media error count of eternus disk drive
eternus_drive_driveerror_CountEternus Drive Error Countcount1.0.0This metric displays the drive error count of eternus disk drive
eternus_drive_driveRecoverederror_CountEternus Drive Recovered Error Countcount1.0.0This metric displays the drive recovered error count of eternus disk drive
eternus_drive_smartevent_CountEternus Drive Smart Event Countcount1.0.0This metric displays the smart event count of eternus disk drive
eternus_drive_IOTimeout_CountEternus Drive IO Timeout Countcount1.0.0This metric displays the IO Timeout count of eternus disk drive
eternus_drive_linkerror_CountEternus Drive Link Error Countcount1.0.0This metric displays the link error count of eternus disk drive
eternus_drive_checkcodeerror_CountEternus Drive Check Code Error Countcount1.0.0This metric displays the checkcode error count of eternus disk drive
Eternus RAID Groupeternus_raidgroup_statusEternus Raid Group Status1.0.0This metric displays the status of RAID Group of an eternus device.Possible values are Available:0,Spare in Use:1,SED Locked:2
eternus_raidgroup_UsedCapacityEternus RAID Group Used CapacityMB1.0.0This metric displays the used capacity of eternus RAID Group in MB
eternus_raidgroup_Capacity_UtilizationEternus RAID Group Capacity Utilization%1.0.0This metric displays the capacity utilization of eternus RAID Group in percentage
Eternus Volumeeternus_volume_StatusEternus Volume Status1.0.0This metric displays the status of volume of an eternus device.Possible Values are Available:0,Other:1
Eternus Pooleternus_thinprovisioning_StatusEternus Thin Provisioning Status1.0.0This metric displays the thin provisioning enable status of an eternus device.Possible values are Enable:0,Disable:1
eternus_thin_pro_pool_StatusEternus Thin Provisioning Pool Status1.0.0This metric displays the status of thin provisioning pool in an eternus device.Possible values are Available:0,Other:1.
eternus_thin_pro_pool_UsedCapacityEternus Thin Provisioning Pool Used CapacityTB1.0.0This metric displays the used capacity of a TPP in eternus device
eternus_thin_pro_pool_UtilizationEternus Thin Provisioning Pool Utilization%1.0.0This metric displays the utilization of TPP in an eternus device

Default Monitoring Configurations

Eternus has a default Global Device Management Policies, Global Templates, Global Monitors and Global Metrics in OpsRamp. Users can customize these default monitoring configurations as per your business use cases by cloning respective Global Templates and Global Device Management Policies. OpsRamp recommends doing this activity before installing the app to avoid noise alerts and data.

  1. Default Global Device Management Policies

    OpsRamp has a Global Device Management Policy for each Native Type of Eternus. You can find those Device Management Policies at Setup > Resources > Device Management Policies, search with suggested names in global scope. Each Device Management Policy follows below naming convention:

    {appName nativeType - version}

    Ex: eternus Eternus Storage - 1 (i.e, appName = eternus, nativeType = Eternus Storage, version = 1)

  2. Default Global Templates

    OpsRamp has a Global Template for each Native Type of Eternus. You can find those templates at Setup > Monitoring > Templates, search with suggested names in Global Scope. Each template follows below naming convention:

    {appName nativeType 'Template' - version}

    Ex: eternus Eternus Storage Template - 1 (i.e, appName = eternus, nativeType = Eternus Storage, version = 1)

  3. Default Global Monitors

    OpsRamp will have a Global Monitors for each Native Type which has monitoring support. You can find those monitors at Setup > Monitoring > Monitors, search with suggested names in global scope. Each Monitors follows below naming convention:

    {monitorKey appName nativeType - version}

    Ex: Eternus Storage Monitor eternus Eternus Storage 1(i.e, monitorKey = Eternus Storage Monitor, appName = eternus, nativeType = Eternus Storage, version = 1)

Configure and Install the Fujitsu ETERNUS Integration

  1. From All Clients, select a client.
  2. Go to Setup > Account.
  3. Select the Integrations and Apps tab.
  4. The Installed Integrations page, where all the installed applications are displayed.
    Note: If there are no installed applications, it will navigate to the Available Integrations and Apps page.
  5. Click + ADD on the Installed Integrations page. The Available Integrations and Apps page displays all the available applications along with the newly created application with the version.
    Note: You can even search for the application using the search option available. Also you can use the All Categories option to search.
Fujitsu Eternus
  1. Click ADD in the Fujitsu ETERNUS tile.
  2. In the Configurations page, click + ADD. The Add Configuration page appears.
  3. Enter the below mentioned BASIC INFORMATION:
FunctionalityDescription
NameEnter the name for the configuration.
Eternus IP Address/Host NameHost name or the IP address provided from the installation.
Eternus SSH PortSSH Port information.

Note: By default 22 is selected.
Eternus CredentialsSelect the credentials from the drop-down list.

Note: Click + Add to create a credential.

Notes:

  • Eternus IP Address/Host Name and Eternus SSH Port should be accessible from Gateway.
  • App Failure Notifications: if turned on, you will be notified in case of an application failure that is, Connectivity Exception, Authentication Exception.
  1. Select the below mentioned Custom Attribute:
FunctionalityDescription
Custom AttributeSelect the custom attribute from the drop down list box.
ValueSelect the value from the drop down list box.

Note: The custom attribute that you add here will be assigned to all the resources that are created by the integration. You can add a maximum of five custom attributes (key and value pair).

  1. In the RESOURCE TYPE section, select:
    • ALL: All the existing and future resources will be discovered.
    • SELECT: You can select one or multiple resources to be discovered.
  2. In the DISCOVERY SCHEDULE section, select Recurrence Pattern to add one of the following patterns:
    • Minutes
    • Hourly
    • Daily
    • Weekly
    • Monthly
  3. Click ADD.
Fujitsu Eternus

Now the configuration is saved and displayed on the configurations page after you save it.
Note: From the same page, you may Edit and Remove the created configuration.

  1. Under the ADVANCED SETTINGS, Select the Bypass Resource Reconciliation option, if you wish to bypass resource reconciliation when encountering the same resources discovered by multiple applications.

    Note: If two different applications provide identical discovery attributes, two separate resources will be generated with those respective attributes from the individual discoveries.

  2. Click NEXT.

  3. (Optional) Click +ADD to create a new collector by providing a name or use the pre-populated name.

Veeam
  1. Select an existing registered profile.
Veeam
  1. Click FINISH.

The application is installed and displayed on the INSTALLED INTEGRATION page. Use the search field to find the installed integration.

Modify the Configuration

View the Fujitsu Eternus details

The Fujitsu Eternus integration is displayed in the Infrastructure > Resources > Storage. You can navigate to the Attributes tab to view the discovery details, and the Metrics tab to view the metric details for Fujitsu Eternus.

Fujitsu Eternus
Fujitsu Eternus

Resource Filter Input keys

Click here to view the Supported Input Keys
Resource TypeSupported Input Keys
All TypesresourceName
hostName
aliasName
dnsName
ipAddress
macAddress
os
make
model
serialNumber
Location
Eternus StorageCache Mode
Device Identification Number
Operation Mode
Remote Support
Eternus Controller EnclosureType
Eternus Drive EnclosureType
Eternus Disk DriveSize
Speed (rpm)
Type
Usage
Eternus RAID GroupAssigned CM
RAID Level
Eternus VolumeRG or TPP or FTRP Name
RG or TPP or FTRP No.
Size(MB)
Type
Eternus PoolDisk Attribute
RAID Level

Supported Alert Custom Macros

Customize the alert subject and description with below macros then it will generate alert based on customisation. Supported macros keys:

Click here to view the alert subject and description with macros

                                ${resource.name}

                                ${resource.ip}

                                ${resource.mac}

                                ${resource.aliasname}

                                ${resource.os}

                                ${resource.type}

                                ${resource.dnsname}

                                ${resource.alternateip}

                                ${resource.make}

                                ${resource.model}

                                ${resource.serialnumber}

                                ${resource.systemId}

                                ${Custome Attributes in the resource}

                                ${parent.resource.name}

Risks, Limitations & Assumptions

  • Application can handle Critical/Recovery failure notifications for below two cases when user enables App Failure Notifications in configuration
    • Connectivity Exception
    • Authentication Exception
  • Application will not send any duplicate/repeat failure alert notification until the already existed critical alert is recovered.
  • OpsRamp has validated this application with an Eternus model which has product code as “ET203 BU” and product name as “Eternus DX200 S3” which belongs to the product family of “Eternus DX.
  • Support for Macro replacement for threshold breach alerts (i.e, customisation for threshold breach alert’s subject, description).
  • No support of showing activity log and applied time.
  • Application is not compatible with Cluster Gateway.
  • This application supports both Classic Gateway and NextGen Gateway.
