OpsRamp now supports multi-tenancy within a single Kubernetes cluster, allowing customers to deploy and register multiple Gateway instances either across different tenants or within the same tenant. This is achieved by leveraging Kubernetes namespaces, which enable logical isolation of Gateway services while sharing the underlying cluster infrastructure. This approach provides the efficient resource utilization, and operational scalability whether the Gateways are serving different tenants or the same tenant.

Prerequisites

Before deploying multiple Gateways using the Multi-Tenancy model, ensure the following prerequisites are met based on your deployment method:

  1. Single-Node Deployment using OpsRamp-provided ISO/OVA
    Refer to the Single-Node Deployment Guide for detailed instructions on setting up a Gateway on a standalone node using the OpsRamp-provided ISO or OVA image.

  2. Multi-Node High Availability (HA) Deployment using OpsRamp-provided ISO/OVA
    For HA setup across multiple nodes, refer to the Multi-Node Deployment guide to configure a resilient Gateway cluster.

  3. Kubernetes Cluster with OpsRamp Bootstrap Tool
    If you are deploying the Gateway in your own Kubernetes environment using the OpsRamp Bootstrap Tool, follow the steps outlined in the Install Gateway Using OpsRamp Bootstrap Tool Guide.

  4. Namespace Requirements
    When implementing multi-tenancy in a Kubernetes cluster using namespaces:

    • A dedicated namespace must be created for each Gateway. For example, if deploying three Gateways, you must create three separate namespaces.
    • Namespaces help isolate resources, configurations, and workloads, enabling better tenant separation and operational manageability.
    • Ensure that your Kubernetes cluster has sufficient compute, memory, and storage resources to host multiple namespaces and their associated workloads.
    • It is recommended to scale your cluster vertically or horizontally as needed to support multiple Gateways.
    • For high availability and resilience, retain at least one idle node to handle failover scenarios.

Multi Tenancy Use cases

Use Case 1: Gateways Registered to Different Tenants


As illustrated in the diagram, each Gateway instance is deployed in its own dedicated Kubernetes namespace within the same cluster:

  • gateway-service1 is deployed in Namespace A and registered to Tenant A.
  • gateway-service2 is deployed in Namespace B and registered to Tenant B.
  • gateway-service3 is deployed in Namespace C and registered to Tenant C.

This architecture supports scalable and isolated multi-Gateway deployments while maintaining efficient resource utilization across tenants.

Use Case 2: Multiple Gateways Registered to the Same Tenant


Instead of provisioning a separate Kubernetes cluster for each Gateway, you can deploy multiple Gateways in different namespaces within the same cluster, all registered to the same tenant. This enables:

  • Better resource utilization
  • Simplified operations
  • Avoidance of cluster sprawl

Example deployment:

  • gateway-service1 is deployed in Namespace A and registered to Tenant X.
  • gateway-service2 is deployed in Namespace B and also registered to Tenant X.
  • gateway-service3 is deployed in Namespace C and again registered to Tenant X.

By reusing the same cluster and isolating each Gateway at the namespace level, you reduce infrastructure overhead while maintaining separation and scalability. Simply scale the cluster vertically (increase resources per node) or horizontally (add more nodes) as needed to support additional Gateways.

Key Considerations for Multi-Tenant Gateway Deployments

  1. Namespace Isolation
    • A unique Kubernetes namespace must be created for each Gateway instance.
    • For example, if you plan to deploy 3 Gateways, you should pre-create 3 distinct namespaces (e.g., gateway-ns-1, gateway-ns-2, gateway-ns-3).
    • Namespace-based isolation ensures that Gateway components (pods, config maps, secrets, services) remain logically separated and manageable.

  2. Resource Planning
    • Ensure that your Kubernetes cluster is provisioned with adequate CPU, memory, and storage to support all Gateway instances.
    • Resources can be scaled either vertically (increasing the size of existing nodes) or horizontally (adding more nodes to the cluster).
    • Monitor cluster usage regularly to prevent resource contention between Gateways.

  3. High Availability and Resilience
    • It is recommended to keep at least one idle node in the cluster as a buffer for failover scenarios.
    • This idle node can absorb workloads from any failed node, ensuring Gateway availability and minimizing downtime.

Deployment Steps

Step 1: Create Kubernetes Namespaces

Run the following command on any node in your Kubernetes cluster to create a dedicated namespace for each Gateway instance:

kubectl create namespace <namespace-name>

Example:

root@node1:/home/gateway-admin# kubectl create namespace gateway-1
namespace/gateway-1 created

root@node1:/home/gateway-admin# kubectl create namespace gateway-2
namespace/gateway-2 created

Step 2: Register Gateways to the OpsRamp Cloud

Use the opsramp-collector-start install command to register each Gateway. Ensure the correct namespace and credentials are used for each deployment.

Register via Direct Connection (No Proxy)

opsramp-collector-start install \
  --environment {Environment} \
  --url {OpsRamp Server URL} \
  --key {Gateway Authentication Token} \
  --config {Path to YAML Config File} \
  --namespace {Namespace} \
  --gateway-name=<gateway-name>

Register through a Proxy (Without Authentication)

opsramp-collector-start install \
  --environment {Environment} \
  --url {OpsRamp Server URL} \
  --key {Gateway Authentication Token} \
  --proxy-protocol {http|https} \
  --proxy-ip {Proxy IP Address} \
  --proxy-port {Proxy Port} \
  --namespace {Namespace} \
  --gateway-name=<gateway-name>

Register through a Proxy (With Authentication)

opsramp-collector-start install \
  --environment {Environment} \
  --url {OpsRamp Server URL} \
  --key {Gateway Authentication Token} \
  --proxy-protocol {http|https} \
  --proxy-ip {Proxy IP Address} \
  --proxy-port {Proxy Port} \
  --proxy-username {Proxy Username} \
  --proxy-password {Proxy Password} \
  --namespace {Namespace} \
  --gateway-name=<gateway-name>

Example: Registering Gateway-1

opsramp-collector-start install \
  --environment k8s \
  --url gatewaytest.api.opsramp.net \
  --key 06d49ab5-a589-44f2-a68b-ee35405d5701 \
  --namespace gateway-1 \
  --gateway-name=gateway-1

Sample Output:

System requirements check passed ✔
Repository check passed ✔
Coredns status check passed ✔
OpsRamp cloud checks passed ✔
Gateway registration pre-checks passed ✔

Installing Agent...
Pulled: opsramp-nextgen-agent:2.0.0
NAMESPACE: gateway-1
STATUS: deployed

Pulled: nextgen-gw:19.0.0
NAMESPACE: gateway-1
STATUS: deployed

OpsRamp Gateway installed successfully.

Example: Registering Gateway-2

opsramp-collector-start install \
  --environment k8s \
  --url gatewaytest.api.opsramp.net \
  --key 28128ba2-72de-4f92-8c79-362c778d1744 \
  --namespace gateway-2 \
  --gateway-name=gateway-2

Sample Output:

System requirements check passed ✔
Repository check passed ✔
Coredns status check passed ✔
OpsRamp cloud checks passed ✔
Gateway registration pre-checks passed ✔

OpsRamp Agent already installed
Pulled: nextgen-gw:19.0.0
NAMESPACE: gateway-2
STATUS: deployed

OpsRamp Gateway installed successfully.

Step 3: Post-Installation Validation

After deploying the Gateways, validate their status:

Check Gateway Pod Status:

Replace with the respective Gateway namespace (e.g., gateway-1, gateway-2).
Example:

kubectl get pods -n gateway-1
kubectl get pods -n gateway-2

*Sample Outputs

Check Tunnel Status:

Ensure each Gateway has successfully established a tunnel connection to the OpsRamp Cloud. Use the OpsRamp UI or CLI as applicable to verify tunnel status.
